Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M

Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M

    • Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M
    • Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M
    • Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M
    • Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M
  • Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M

    Product Details:

    Place of Origin: CHINA
    Brand Name: BM
    Certification: CE,CCC
    Model Number: BM-GABIONS003

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 basket
    Price: $65 - $156 per basket
    Packaging Details: plastic and wooden pallet
    Delivery Time: 14-20 days after get the deposite
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,paypal
    Supply Ability: 200 unit per week
    Contact Now
    Detailed Product Description
    Material: Galvanized Mesh Type: Welded Gabions
    Wire Dia: 3.0mm-5.0mm Opening Size: 100mm*100mm
    Basket Size: 2000*1000*500mm Mesh:Tensile: 380N/mm2 - 550N/mm2
    Application: Rockfall Prevention And Soil Erosion Protection Fishing: Heavy Duty Galvanized Or Galfan Galvanized
    Packing: Wooden Pallet Transport: By Sea

    Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M



    welded gabion basket should be provided with lacing wire for site assembly, which should be? of minimum wire diameter 2.2mm for final joining.



    Popular in the worldwide.



    Spec:

    Material:Hot dip galvanized

    Aperture size:75*75mm,of course,50*50mm,100*100,50*100mm,75*150mm,150*150mm also could be made as request.

    Gabion Basket/Gabion Box size:2M*1M*0.5M,1M*1M*1M,2M*1M*1M,could be made as client request



    Welded gabions are wire mesh containers welded with high quality steel mesh. They can be filled on site with hard durable stone materials to form mass gravity retaining structures. Owing to their inflexibility, welded gabions can not adapt to differential settlement or be used in water courses. In comparison with woven wire gabions, welded gabions offer a higher strength. In order to meet different project requirements, various wire diameters and unit sizes are available for welded gabion boxes



    Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M





    Major Applications of Welded Gabions:
    1. Retaining wall structures
    2. Prevention of current scour and erosion control
    3. Bridge protection
    4. Hydraulic structures, dams and culverts
    5. Embankment protection
    6. Rockfall prevention and soil erosion protection



    Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M



    Mesh Tensile strength: 380N/mm2 - 550N/mm2

    Diameter: 3.0mm-6.0mm

    Finishing: heavy duty galvanized or galfan galvanized Coating weight: 245g-350g Lacer and spacer: standard.Packing: Flat packed on pallet.



    Heavy Galvanized Material Square welded galvanized Gabion Basket 2M X 1M X 1M
