| Place of Origin: | China |
| Brand Name: | BM |
| Certification: | CE,CCC |
| Model Number: | BM-SCREEN |
| Minimum Order Quantity: | 1 Piece |
|---|---|
| Price: | Be Negotiated |
| Packaging Details: | Water-Proof Plastic Film And Wooden Case |
| Delivery Time: | 7-10 Days After Get The Deposite |
| Payment Terms: | D/A, L/C, D/P, T/T, Western Union, MoneyGram,paypal |
| Supply Ability: | 50000 Pcs Per Week |
| Product Name: | Screen Filter Disc | Feeature: | Flexible Working |
|---|---|---|---|
| Material: | SUS304,316,316L | Technology: | Welding Spot |
| Mesh Type: | Plain Weave And Dutch Weave | Application: | Filtering |
| Tooling: | With Charge | Micron: | 50 |
50 Micron Round Screen Filter Disc 304 Stainless Steel Etched 250 Mesh Filter
Screen Filter Disc Mesh Description
|
Material type:
|
stainless steel 201,304 316 316L,2080,601,carbon steel,iron,copper,brass
|
||
|
Shape:
|
strainer,sieve,element,cartridge,disc,pleasted filter
|
||
|
processing way:
|
welded,dot welded,woven,folded,punching,sintered
|
||
|
shape:
|
rectangle,square,round,oval,circular,rectangular,cap,waist and abnormity
|
||
|
structure:
|
single layer,double layer or multi-layer
|
||
|
edge treatment:
|
edge surounded with stainless steel sheet,bigger stainless steel wire, mesh folded then spot welded
|
||
|
raw material:
|
stainless steel plate,woven wire mesh,sintered wire mesh,expanded wire mesh,perforated wire mesh,wedge wire screen,black wire mesh,galvanized wire mesh and so on
|
||
|
size:
|
desinged according to customer`s requirement
|
||
|
filtering rate:
|
2-400micron
|
||
|
hole shape:
|
square,rectangle,round,diamond,and other special kinds as per customer`s requirement.
|
||
Screen Filter Disc Mesh Series
Single extruder screens Filter Disc
They are predominantly used in the extruded profiles and blown film industries where the contamination of the raw material is less and there is often lower pressure within the extruder head.
Multilayer extruder screens Filter Disc
Many single layer screens are assembled properly and spot welded with each other to form multilayer. It can be with or without selvage. Multilayer extruder screen is used for fine and thin level of extrusion to prevent the mixing of foreign particles. Multilayer Extruder Screen helps in making extrusion more clear and clean.
Mesh :10mesh-500mesh
Layer:single,double,multilayer.
Disc Diameter: 50mm -580mm
The different wire meshes are processing as per desired shapes and sizes; assembled properly and spot welded with each other to form multilayer.
Filter Disc Mesh Benifits
Filter Disc Mesh Detailed Specification
| Mesh/Inch | Wire Diameter | Aperture | Open Area | Weight(LB)/100 Square Foot | ||
| Inch | MM | Inch | MM | |||
| 1x1 | .080 | 2.03 | .920 | 23.37 | 84.6 | 41.1 |
| 2X2 | .063 | 1.60 | .437 | 11.10 | 76.4 | 51.2 |
| 3X3 | .054 | 1.37 | .279 | 7.09 | 70.1 | 56.7 |
| 4X4 | .063 | 1.60 | .187 | 4.75 | 56.0 | 104.8 |
| 4X4 | .047 | 1.19 | .203 | 5.16 | 65.9 | 57.6 |
| 5X5 | .041 | 1.04 | .159 | 4.04 | 63.2 | 54.9 |
| 6X6 | .035 | .89 | .132 | 3.35 | 62.7 | 48.1 |
| 8X8 | .028 | .71 | .097 | 2.46 | 60.2 | 41.1 |
| 10X10 | .025 | .64 | .075 | 1.91 | 56.3 | 41.2 |
| 10X10 | .020 | .51 | .080 | 2.03 | 64.0 | 26.1 |
| 12X12 | .023 | .584 | .060 | 1.52 | 51.8 | 42.2 |
| 12X12 | .020 | .508 | .063 | 1.60 | 57.2 | 31.6 |
| 14X14 | .023 | .584 | .048 | 1.22 | 45.2 | 49.8 |
| 14X14 | .020 | .508 | .051 | 1.30 | 51.0 | 37.2 |
| 16X16 | .018 | .457 | .0445 | 1.13 | 50.7 | 34.5 |
| 18X18 | .017 | .432 | .0386 | .98 | 48.3 | 34.8 |
| 20X20 | .020 | .508 | .0300 | .76 | 36.0 | 55.2 |
| 20X20 | .016 | .406 | .0340 | .86 | 46.2 | 34.4 |
| 24X24 | .014 | .356 | .0277 | .70 | 44.2 | 31.8 |
| 30X30 | .013 | .330 | .0203 | .52 | 37.1 | 34.8 |
| 30X30 | .012 | .305 | .0213 | .54 | 40.8 | 29.4 |
| 30X30 | .009 | .229 | .0243 | .62 | 53.1 | 16.1 |
| 35X35 | .011 | .279 | .0176 | .45 | 37.9 | 29.0 |
| 40X40 | .010 | .254 | .0150 | .38 | 36.0 | 27.6 |
| 50X50 | .009 | .229 | .0110 | .28 | 30.3 | 28.4 |
| 50X50 | .008 | .203 | .0120 | .31 | 36.0 | 22.1 |
| 60X60 | .0075 | .191 | .0092 | .23 | 30.5 | 23.7 |
| 60X60 | .007 | .178 | .0097 | .25 | 33.9 | 20.4 |
| 70X70 | .0065 | .165 | .0078 | .20 | 29.8 | 20.8 |
| 80X80 | .0065 | .165 | .0060 | .15 | 23.0 | 23.2 |
| 80X80 | .0055 | .140 | .0070 | .18 | 31.4 | 16.9 |
| 90X90 | .005 | .127 | .0061 | .16 | 30.1 | 15.8 |
| 100X100 | .0045 | .114 | .0055 | .14 | 30.3 | 14.2 |
| 100X100 | .004 | .102 | .0060 | .15 | 36.0 | 11.0 |
| 100X100 | .0035 | .089 | .0065 | .17 | 42.3 | 8.3 |
| 110X110 | .0040 | .1016 | .0051 | .1295 | 30.7 | 12.4 |
| 120X120 | .0037 | .0940 | .0064 | .1168 | 30.7 | 11.6 |
| 150X150 | .0026 | .0660 | .0041 | .1041 | 37.4 | 7.1 |
| 160X160 | .0025 | .0635 | .0038 | .0965 | 36.4 | 5.94 |
| 180X180 | .0023 | .0584 | .0033 | .0838 | 34.7 | 6.7 |
| 200X200 | .0021 | .0533 | .0029 | .0737 | 33.6 | 6.2 |
| 250X250 | .0016 | .0406 | .0024 | .0610 | 36.0 | 4.4 |
| 270X270 | .0016 | .0406 | .0021 | .0533 | 32.2 | 4.7 |
| 300X300 | .0051 | .0381 | .0018 | .0457 | 29.7 | 3.04 |
| 325X325 | .0014 | .0356 | .0017 | .0432 | 30.0 | 4.40 |
| 400X400 | .0010 | .0254 | .0015 | .370 | 36.0 | 3.3 |
| 500X500 | .0010 | .0254 | .0010 | .0254 | 25.0 | 3.8 |
| 635X635 | .0008 | .0203 | .0008 | .0203 | 25.0 | 2.63 |
Filter Disc Mesh Application
